SYEX EMW3162 Low Power WIFI Module Serial Port Transmission STM32F205 Kernel Cloud Services

Description

Type : Voltage RegulatorBrand Name : ReYeBuSupply Voltage : 3.3Vis_customized : YesApplication : Mobile PhoneModel Number : WIFI ModuleCondition : NewEMW3162 Low Power WIFI Module Serial Port Transmission STM32F205 Kernel Cloud ServicesDescription:Function:Built in 120MHz frequency STM32F205RG microcontroller, embedded 1M byte Flash,128K byteSupport Easy Link smart networking capabilities (provided by APP)Single operation voltage: 3.3VTypical power consumption:When 20kbps transmission data (transmission cycle 100ms), the average power consumption is about 24mAOnline standby: power consumption is about 7mAFull functionality WiFi Unicom:Supports IEEE 802.11 b/g/n, WiFi band 1-13Transmit power: 18dBm@11b, 15dBm@11g, 14.5dBm@11nReceiving sensitivity: -96dBmWPS 2.0Encryption mode:WEP,WPA/WPA2 PSK/EnterpriseMultiple energy saving modePackage Included:1 * WIFI module
